SparkFun Produkt

Varenr. ROB-13260

Hobby Motor and Encoder Kit

281,25
DKK

På fjernlager Bestil før Torsdag kl15 og varen afsendes Tirsdag ugen efter

Køb flere og spar:

281,25 DKK pr. stk. -
255,00 DKK pr. stk.
Spar 9%
229,00 DKK pr. stk.
Spar 19%

This item is only sold in badges of .

eller

Du skal vælge en variant.
Minimumsmængde nået.
Maksimal mængde nået
  • Fri fragt ved køb over 999 kr

    Til pakkeshop i DK Læs mere.

  • 60 dages returret

    Se venligst Handelsbetingelser Læs mere.

  • Danmarks største udvalg

    Over 4000 produktnumre Læs mere.

This is the Hobby Motor and Encoder Kit from DAGU, an inexpensive and reliable set of add-ons for your next robotic project. Inside this kit are three pairs of items: wheels, gearmotors, and wheel encoders (including everything you need to hook them up). The Hobby Motor and Encoder Kit is perfect for providing beginners with a cheap and easy to use setup or if you just need a few extra parts.

The off set gear motors included with this kit require a voltage of 3-6V with a no load current of 200mA and possess a stall current of 3A@6V (1.5A@3V), a gearbox ratio of 48:1, and a wheel speed of 65RPm at 3V unloaded. Each wheel encoder in this kit requires a supply voltage of 3-24V, a supply current of 4mA, consists of two neodymium 8-pole magnets with rubber hubs, and two hall-effect sensors terminated with 150mm cables and 3-pin female servo headers.

Includes:

  • 2x DG02S Mini DC Gear Motor
    • 2x Wheel - 65mm
    • 1x Wheel Encoder Kit (Set of 2)

Features:

  • Gear Motor
    • Voltage: 3V – 6V
    • No Load Current: 200mA
    • Stall Current: 3A @ 6V (1.5A @ 3V)
    • Gearbox Ratio: 48:1
    • Wheel Speed: 65rpm @ 3V unloaded (Recommended)
  • Wheel Encoder
    • Voltage: 3V – 24V with reverse polarity protection
    • Encoder Type: 8-pole neodymium magnet and hall-effect sensor
    • Encoder Output: Open drain with short circuit protection

Documents:
