DFRobot

Varenr. DRI0050

Light & Motor Driver for Python (V1.0)

143,75
DKK

På fjernlager Bestil før Onsdag kl 20 og varen afsendes ugen efter

Køb flere og spar:

143,75 DKK pr. stk. -
127,00 DKK pr. stk.
Spar 12%
111,00 DKK pr. stk.
Spar 23%

This item is only sold in badges of .

eller

Du skal vælge en variant.
Minimumsmængde nået.
Maksimal mængde nået
  • Fri fragt ved køb over 999 kr

    Til pakkeshop i DK Læs mere.

  • 60 dages returret

    Se venligst Handelsbetingelser Læs mere.

  • Danmarks største udvalg

    Over 4000 produktnumre Læs mere.

Documents

  • Product wiki
  • Schematic
  • DRI0050-V1.0-3D-STEP File
  • DRI0050-V1.0-2D-DXF File
  • Introduction

    This is a PWM driver board with four adjustment methods, namely, Python code direct control, PC host computer control, UART communication programming control, and potentiometer manual control.

    It is used in application scenarios such as DC motor speed control and light adjustment.

    This product supports 5V~24V wide voltage input, and has a load capacity of 10A, which can drive a DC motor of about 10W or a LED strip light of about 5 meters.

    It is suitable for water pump water volume control, cooling fan speed control, light brightness adjustment, power tool transformation, motor/LED strip product testing, motor speed automation control, lighting effect automation control and other scenes.

    Board Overview


    Product Dimension

    Features

  • Simple and easy to use

    Python code programming, no motherboard or adapter required.

  • Plug and play

    Windows software control, no programming required,

  • UART communication control

    Convenient for long-term use of embedded equipment.

  • External potentiometer control

    Manual control, no programming required.

  • Standard MODBUS protocol

    The protocol is public, and you can flexibly customize your own control method.

  • 5V~24V wide voltage support

    Suitable for various motors and light strips.

  • Driven by high current MOS tube, load capacity of 10A
  • Specification

  • Input Voltage Range: 5V~24V
  • Maximum Control Current: 10A
  • PWM Duty Ratio Adjustment Range: 0~255
  • PWM Frequency Adjustment Range: 183Hz ~ 46875Hz
  • Number of PWM Channels: 1 channel
  • Start/Stop Button: x1
  • Control Mode:

           External potentiometer adjustment

           UART communication control

           USB port host computer control

           Python control

  • USB Interface: Type-C
  • UART Interface: PH2.0-4P
  • External Potentiometer Interface: 2.54 pin header, binding post
  • Mounting Hole Size: 30mm x 50mm, diameter 3.1mm
  • PCB Size: 37mm x 57mm / 1.46 x 2.24 inches
  • Shipping List

  • Light & Motor Driver for Python x1
  • Gravity 4P Cable (Connect to UART) x1
